#2 Dings electromagnet self-cleaning severe-duty overhead cross belt 36” width, Dings overhead crossbelt self-cleaning electromagnet
Dings suspension magnet belt width 36” - with belt-armor clad 24” wide, motor 5HP- 208-230/460, 1725RPM., frame 184T, 3 phase, Falk speed reducer: model: 4203J 14, ratio: 14.031 to 1, this magnet consist of 3 separate magnets with the right magnet adjustable left or right with a powered mechanical screw-type mechanism, We don't have the Rectifier, but is available thru the MFG/Dings, approximate outside dimensions: length 14 ft 6 inches, width 6 ft 2 inches, approximate weight 12,000 lbs., suspension stand and turnbuckles available, Call for a delivered price
Left Magnet Info: watts 5150 , product # 33 OH , part # 101573, serial#12512-02 , volts 115 DC
Center Magnet Info: watts 5035, product # 2SPL OH, part # 101278, serial#12512-02, volts 115 DC
Right Magnet Info: watts 4061 , product # 22 OH, part # 101075 , serial#12512-02 , volts 115 DC
