2 strand box chain surge bin conveyor

S drive  shaft   keyed side is 2-15/16”

Gear motors VFDs/frequency drives are available are Sold separately

Mac box chain/ drag chain (made in USA), 6” pin to pin, 2” tall+-, ½” thick sidebars, 11 5/16” sidebar width O.D., 10 ¼” bearing length

Chain conveyor inside width: 40 inches.+-

Chain conveyor over length: 31ft.+-

Rex bearings

Hopper dimensions: 7ft deep+-, 7ft 4 inches width

Hopper walls are ¼” thick

Adjustable incline height: front & back upright supports are hinged and the front upright supports can telescope up and down with holes for pins to lock in desired height

2” thick center divider between chains

Conveyor approx.. overall dimensions: length 31ft, height 10ft 8 inches, width 9 ½.ft.+-

Bottom I-Beam frame width 71”, length 20ft 4 inches

Contact us for a delivered price to your location

Approximate shipping weight 23,000 LBS.

31ft twin strand box chain hopper conveyor bin, unused
